The KSY 300D6 is an industrial-grade 300KG heavy-lift unmanned aerial vehicle designed for heavy transport and demanding multi-role missions. Featuring a robust modular design, advanced dual GNSS/RTK positioning, high-capacity battery system, and a rated payload of 300 kg at sea level, it delivers exceptional heavy-duty operational performance.
KSY 300D6 300KG HEAVY-LIFT UNMANNED AERIAL VEHICLE Short Description: The KSY 300D6 is an industrial-grade 300KG heavy-lift unmanned aerial vehicle designed for heavy transport and demanding multi-role missions. Featuring a robust modular design, advanced dual GNSS/RTK positioning, high-capacity battery system, and a rated payload of 300 kg at sea level, it delivers exceptional heavy-duty operational performance. Dimensions & Weight: • Dimensions (propellers folded, arms expanded): <4020*4020*1000 • Dimensions (propellers folded, arms folded): <1900*1900*1900 • Max Takeoff Weight: ≤540 Kg • Rated Payload (sea level): 300 Kg • Empty Weight (excluding battery): ≤180 Kg Battery & Power System: • Operating Voltage Range: 90-117.6V • Total Battery Capacity: ≥24 Kwh • Cycle Life: ≥2000 cycles • Total Battery Weight: ≤120 kg • Charging Ambient Temperature: ≤35°C • Safe Operating Temperature: -40 to +80°C • Safe Operating Altitude: 5000m Flight Performance & Hover: • Max Hover Time (empty load): ≥50 Min • Flight Time at 80% Payload: ≥20 Min • Max Climb Speed: 8 m/s • Max Descent Speed: 8 m/s • Max Horizontal Speed: >20 m/s • Max Operating Altitude: >4500mm • Operating Ambient Temperature: -20°C to +50°C • Waterproof Rating: IP44 Navigation & Positioning System: • Hovering Accuracy (Dual GNSS): Horizontal ±0.5m, Vertical ±0.5m • Hovering Accuracy (RTK): Horizontal ±0.1m, Vertical ±0.1m Control Link & Video Transmission: • Control Link System & Ground Station System: Upgradable • Remote Control Range: ≥15 Km • Video Transmission: High-definition digital video transmission • Decoding: 4K 30fps • Latency: <180 ms, low latency
