The KSY CT-100D6 is an industrial heavy-lift multi-rotor drone engineered for heavy payload transport and complex utility missions. Offering a massive load capacity of 100–200 kg, it features a robust 2900mm wheelbase, dual 24S 44000mAh batteries, H15plus high-performance motors, and advanced lifting functions including weighing, anti-swing, and one-touch unhooking.
KSY CT-100D6 HEAVY MULTI-ROTOR DRONE Short Description: The KSY CT-100D6 is an industrial heavy-lift multi-rotor drone engineered for heavy payload transport and complex utility missions. Offering a massive load capacity of 100–200 kg, it features a robust 2900mm wheelbase, dual 24S 44000mAh batteries, H15plus high-performance motors, and advanced lifting functions including weighing, anti-swing, and one-touch unhooking. General Dimensions & Structure: • Wheelbase: 2900 mm • Product Dimensions (Pitched blade span): 3910 * 3910 * 1004 mm • Product Dimensions (Excluding blade span): 2280 * 2280 * 1004 mm • Product Dimensions (Folded): 1352 * 1417 * 1004 mm • Arm Dimensions: 74 * 80 mm Payload & Capacity: • Load Capacity: 100 – 200 kg Powertrain & Electrical System: • Powertrain (Motor): H15plus • Electrical Control: 300A • Propeller: 73 inches • Battery: 24S 44000mAh * 2 (Zhi'an) • Battery Mounting Method: Dual battery compartment for quick installation Avionics & Control: • Flight Control: Boying / Weike • Remote Control: G20 Mission & Utility Functions: • Lifting Configuration Functions: Weighing / anti-swing / one-touch unhooking
